MIL-DTL-85694A
3.8.3 Labeling. All containers and mailing tubes shall be labeled in accordance with the
applicable federal, state, and municipal laws, statutes, regulations, and ordinances. In addition to
the labeling, the following shall appear on each container.
Shelf Life/Expiration Date
National Stock Number (NSN)
"Keep closed when not in use"
"Store at 50-80 °F"
"Protect from bright light, humidity, and water"
TABLE I. Chemical and physical property requirements and test methods.
Physical property
Requirement
Test Method
Density at 60 °F
report
ASTM D4052
Viscosity (mm2 /s at 100 °C)
16.3 min., 21.9 max.
ASTM D445
Viscosity Index, Min
85
ASTM D2270
Trace Sediment
0.005 ml/100 mL Oil max.
ASTM D2273
Pour point
-12 °C max.
ASTM D97
Flash point, minimum (COC)
243 °C
ASTM D92
Metal Elements (Rotrode-AES)
See Table IV
ASTM D6595
Metal Elements (ICP-AES)
See Table V
ASTM D5185
5
