METRIC
MIL-DTL-85694A
12 August 2013
DoD-S-85694
20 October 1986
DETAIL SPECIFICATION
SPECTROMETRIC OIL STANDARDS
Reinstated after 12 August 2013 and may be used for new and existing designs and acquisitions.
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
1. SCOPE
1.1 Scope. This specification covers the requirements for blended spectrometric oil standards
for use in calibrating or verifying the calibration of spectrometers used in spectrometric analysis
of metallic elements found in oils and other fluids.
1.2 Classification. The blended spectrometric oil standards are of the following types:
Type
Description of the Spectrometric Oil Standards Type
D19-0
Spectrometric oil standards (SOS) with 0 elements
D19-XXX1 Series of Spectrometric oil standards (SOS) with 19 elements (Aluminum, Chromium,
Copper, Iron, Lead, Magnesium, Nickel, Silicon, Silver, Sodium, Tin, Titanium,
Boron, Molybdenum, Zinc, Barium, Cadmium, Manganese, Vanadium).
D12-XXX1 Spectrometric oil standards (SOS) with 12 elements (Aluminum, Chromium, Copper,
Iron, Lead, Magnesium, Nickel, Silicon, Silver, Sodium, Tin, Titanium)
D3-100
Spectrometric oil standards (SOS) with 3 elements (Boron, Molybdenum, Zinc)
D21-XXX1 Spectrometric oil standards (SOS) with 21 elements (Aluminum, Chromium, Copper,
Iron, Lead, Magnesium, Nickel, Silicon, Silver, Sodium, Tin, Titanium, Boron,
Molybdenum, Zinc, Barium, Cadmium, Manganese, Vanadium, Calcium, Phosphorus)
1
Note: The "XXX" is replaced by the corresponding concentration of the elements in the applicable standard.
For example D19-005 contains 5 parts per million (ppm) of the 19 elements listed in the description.
The D19 and D21 series of standards are produced in the nominal concentrations of 5, 10, 30, 50, 80,
100, 120, 300, 500, 700, and 900 ppm. The D12 series of standards are produced in the nominal
concentrations of 5, 10, 30, 50, 100, and 300 ppm.
Comments, suggestions, or questions on this document should be addressed to: Commander,
Naval Air Warfare Center, Aircraft Division, Code 4L8000B120-3, Highway 547, Lakehurst, NJ
08733-5100 or emailed to michael.sikora@navy.mil. Since contact information can change, you
may want to verify the currency of this address information using the ASSIST Online database at
https://assist.dla.mil.
AMSC N/A
FSC 9150
