MIL-PRF-9000J(SH)
TABLE II. Chemical and physical requirements (SAE 15W40 Grade) Continued.
Methods (ASTM unless
Characteristics
Requirements
otherwise noted)
Clear, homogenous, and free
Appearance
Visual examination
from visible water, particles,
and sediments
Low temperature cranking viscosity, cP at
7000 at -25/7000 at -20
D5293
°C, minimum/maximum
Low temperature pumping viscosity, cP at
60,000 at -25
D4684
°C, maximum
NOTES:
1/
No limiting requirements. In conformance testing, values are compared to qualification results (see 4.5).
2/
Test shall be run for 3 hours at specified temperature.
3/
Option A shall not be used. A ring of bubbles around the edge of the graduate shall be considered complete
collapse or 0 mL.
4/
The contractor shall certify that if zinc is present, it is present as zinc dialkyl dithiophosphate, as zinc diaryl
dithiophosphate, or as a combination of the two.
TABLE III. Conformance tests with tolerances.
Test
Tolerances, if applicable
Appearance
-
Gravity, API
+1.0
+0.5 1/
Viscosity, cSt at 100 °C
+10 1/
Viscosity, cSt at 40 °C
Viscosity index
-
+8 1/
Flash point, °C
Pour point, °C
-
Foam test, mL
-
Sulfur, mass %
+20% of original value
Phosphorus, ppm
+10%
Zinc, calcium, and magnesium, ppm
+10%
Total base number, mg KOH/g
-
1/
NOTE:
Shall meet specification requirements.
3.8 Toxicity. When evaluated in accordance with 4.6.5, the oil shall have no adverse effect on the health of
personnel when used for its intended purpose. The oil shall be assessed by the Navy and Marine Corps Public
Health Center (NMCPHC) using the administrative Health Hazard Assessment (HHA). A flowchart for this process
can be found as enclosure (1) of BUMEDINST 6270.8. The HHA is a review of the oil based on information
submitted by the manufacturer to assess health hazards associated with the handling, application, use, and removal
of the product. The oil shall not cause any environmental problems during waste disposal (see 4.6.5 and 6.8).
3.9 Off-gassing. The oil shall be certified for and assigned a usage category of "Limited" in accordance with
7
