MIL-PRF-2104J
TABLE VI. Piston deposit and scuffing control steel piston (1P).
Primary performance criteria
Rated or measured parameter
One-Test
Two-Test
Three-Test
Weighted demerits (WDP), max
350
378
390
Top groove carbon (TGC), demerits, max
36
39
41
Top land carbon (TLC), demerits, max
40
46
49
Average oil consumption, g/hA (0 - 360 h), max
12.4
12.4
12.4
Final oil consumption, g/h (312 - 360 h), max
14.6
14.6
14.6
Piston, ring, and liner scuffing
None
None
None
A
grams per hour
TABLE VII. Piston deposits, oil consumption and scuffing performance (1R).
Primary performance criteria
Rated or measured parameter
One-Test Two-Test Three-Test
Weighted Piston Demerits (WDP), max
382
396
402
Top groove carbon (TGC), demerits, max
52
57
59
Top land carbon (TLC), demerits, max
31
35
36
Initial oil consumption (IOC), average (0 - 252 h), g/h, max
13.1
13.1
13.1
Final oil consumption, average (432 - 504 h), g/h, max
IOC + 1.8
IOC + 1.8
IOC + 1.8
Piston, ring, and liner scuffing
None
None
None
Ring sticking
None
None
None
3.4.1.4 Roller follower wear. All grades shall prevent camshaft roller follower
wear in accordance with Table VIII. See section 4.3.4 for the verification test method.
TABLE VIII. Roller follower wear test (RFWT).
Primary performance criteria
Rated or measured parameter
One-Test
Two-Test
Three-Test
Average pin wear, µm, max
7.6
8.4
9.1
3.4.1.5 Sludge control, filterability and sliding valve train wear. All grades shall
prevent sliding valve train wear, filter plugging, and sludge deposits. Oil grades 10W,
30, and 40 shall comply with the requirements of Table IX or Table X. Oil grade 15W-40
shall comply with the requirements of Table IX or Table XI. See section 4.3.5 for the
verification test methods.
8
